There has been a discussion titled [Jersey] Putting the RESTful "connectedness" around my existing Domain objects on the jersey mailing list that is starting up again.

I don't think I have confused HATEOAS with "connectedness", I have a reasonable understanding of resource state, application state and HATEOAS.

See http://www.stucharlton.com/blog/archives/000141.html and this discussion, http://tech.dir.groups.yahoo.com/group/rest-discuss/message/12497, which I see you have contributed to.

I think this final point made by Roy is pretty applicable here:

A REST API should be entered with no prior knowledge beyond the initial URI (bookmark) and set of standardized media types that are appropriate for the intended audience (i.e., expected to be understood by any client that might use the API). From that point on, all application state transitions must be driven by client selection of server-provided choices that are present in the received representations or implied by the user’s manipulation of those representations. The transitions may be determined (or limited by) the client’s knowledge of media types and resource communication mechanisms, both of which may be improved on-the-fly (e.g., code-on-demand). [Failure here implies that out-of-band information is driving interaction instead of hypertext.]

My point is you can't adhere to the HATEOAS constraint, without providing links between resources so the server can guide the client to other application states.

I agree that forms are a better example for explaining state transitions, especially since resource state is likely to be changed by providing forms (as will the User Agent, as Roy mentions); or equivalent form templates/prototypes for other media types.
But to me providing forms or equivalents for other media types is a different and easier problem to solve.

I'm very interested in how to evolve existing systems; I want to leverage the vast islands of information that already exist.

I just want to do it in an elegant way from a code and a web perspective, including the fact that uri's shouldn't change.

URITemplateAspects; LinkAwareModels and LinkTemplateProcessor

In a standard, layered design, you would have these components (see Image):

1. Code-On-Demand
2. View
3. Controller
4-6. Contains the Proposed Abstractions
7. Model
8. Persistent Store - Db; file; jcr; webdav
9. Proxies

Here are some options I have for adding links around some existing system (there are likely more)

Due to the time constraints, the Pros, will be sparse.

Option 1: Add Links via Code-On-Demand.

Add links to my html page via javascript.
I could take my existing html representation and use dhtml to add links.

Cons:
* code-on-demand not available for all user agents or may be disabled
* Proxies can't cache the entire representation
* leak of possible application states to clients that don't need to know
* Detailed knowledge of resource and subresources required to provide "link rich" representations
* Alternative media types may require alternative languages or structure to perform add the links. ie. use of xsl for xml; javascript with svg.

Option 2: Add Links via Views

Cons:
* We all know this is bad
* Detailed knowledge of resource and subresources required to provide "link rich" representations
* different views/media types require the same logic and detailed knowledge of the model
* different views/media types may require some application state knowledge. an admin user may have other links than anon.

Option 3: Add Links via Controllers

Pros:
* Can handle the inclusion/exclusion of links depending on the current application state, regardless of the media type to respond with

Cons:
* Detailed knowledge of resource and subresources required to provide "link rich" representations

Option 4: Add Links via Models

Pros:
* Detailed knowledge of the model and related models belong in the Model

Cons:
* Detailed knowledge of resource links aren't the domain of the models
* Not all possible related models are likely to be represented; to balance performance with types of usage, often some relationships are not modelled, so as to not eager load, very large graphs etc.
* Links are very static, The "next available" application state, still needs to be determined in another layer, like Controller

Option 5: Add Links via Persistent Store

Store partial links in the db

Pros:
* Db driven, easy to update
* Tables have relationships
* easy adoption path
* easy to link to external resources, or resources outside your db schema
* easy to share links at db level, if several systems integrate at that level
* Good for sparse relationships.

Cons:
* Update to change a link, will not play nice with intermediaries nor "cool uris, that don't change"
* Not great for consistent dense relationships, you probably want to model that differently. So with a Parent Child relationship, you wouldn't want something in addition to existing foreign key relations, to redundantly specify that to get to the children of a parent you have a list of /child/xyz links. but by having that specified in the URITemplateAspect then you are managing that once, close to the data.
* Relationships are not always defined in Foreign Keys
* Links are very static, The "next available" application state, still needs to be determined in another layer, like Controller
* Only a partial solution for more dynamic aspect of determining what application states make sense, still needs to be done in another layer.
* May be invasive, links stored in columns or other tables, no good if you've got a locked down schema.

Thoughts

Models shouldn't have relationships to hardcoded resources, like "/resource/50", but they could have a semantic relationship to "/resource/{id}" or "/resource/{id};role={role}" under certain conditions.

There is a place for such LinkAwareModels (Component no. 5), as long as the links are isolated and only contain semantic relationships, they are not urls.

The Links from Models to Resources are isolated and encapsulated within its own abstraction; which gives us component no. 6 URITemplateAspects (maybe just simplify this to LinkTemplateAspect).

Possible "Application States" are dependent on the request, even though a request must be STATELESS, possible "Application States" may still be determined by the security access; restrictions of media-types or client, which should all be part of the request. If you do stuff with user roles, then make sure you encode within your url.

Component no. 4 is our LinkTemplateProcessor(s) and its responsibility is to evaluate URITemplates within the LinkAwareModels/entities and to determine appropriate state transitions based on the request.

This leads us to the final Option ( well, for this post )

Option 6: Semantic relationships of a "Model to resources" definied via URITemplateAspect and a LinkTemplateProcessor to evaluate the relationships (URITemplates) and sub-entities to determine other "application states"

Pros:
* Detailed knowledge of the model and related models belong in the Model
* Detailed knowledge of the model to resource of interest is a concern isolated in the URITemplateAspects
* Any possible relationships to other resources can be defined
* Links are very dynamic. The possible state transitions can be determined by the LinkTemplateProcessor, but it can do so decoupled from the detailed relationships of the model to other resources.

The semantic relationships that are defined in the LinkAwareModels, can include uri and other attributes, like rel. The LinkTemplateProcessor can evaluate a lot of the current application state (but not all as the User Agent may have representations from other servers or representations that have been modified by Code-On-Demand) in combination with the semantic relationship to determine the ultimate value of the link to use (relative preferred, of course) and it can determine if that link is a valid state transition. Only if you are an admin do you see this link; or the link retains the current media-type used for this request; so a request for /country/AU.html includes links to cities.html, not just cities. The default negotiation might be something if that is not specified.

* The Processor can operate on objects, prior to rendering to a particular media-type, so if you have a single object model that can render to multiple media-types, you could have less code

Conclusion

What do you call, this, maybe Rich Interconnected Model View Resource RIMVR.
Rich in relation to having deep links within a resource representation and from the applicability of those links. That actual uri templates are evaluated late and with some context of the request and application state.

The use of these abstractions, in no way make an application RESTful, that is up to the developers, but hopefully by following some abstractions, like these we will get some clean code and some better understanding of RESTful APIs.

I have some old code, to show this working.
One day I'll get a chance to clarify terms and simplify the code
